Regenerative endodontic procedure using Emdogain: a case series

Journal of Medical Case Reports volume 19, Article number: 205 (2025) Cite this article

Abstract

Background

Emdogain (Straumann® Emdogain®, Basel, Switzerland) is an enamel matrix derivative and has an important role in odontogenesis, by potentializing pulp tissue repair and regeneration, as showed in biological studies. Nevertheless, the benefits of using Emdogain as a scaffold in clinical regenerative endodontic procedures has not been demonstrated and is not yet fully understood. The aim of this report was to show three clinical cases that had different preoperative conditions and underwent pulp regenerative procedures under an identical clinical protocol. This report also aimed to show the value of using Emdogain to guide angiogenesis and the healing process by reporting clinical and radiographical results. This is a pioneering study on the use of Emdogain in regenerative endodontic procedures in humans.

Cases presentation

This report is a retrospective description of clinical findings from three regenerative treatments conducted under an identical protocol in two appointments using Emdogain as a scaffold. The three young Brazilian patients, aged 8, 8, and 12 years old (one female and two male), are from São Luís city, state of Maranhão. All three patients identify as Pardo ethnicity with brown skin color, come from low-income backgrounds, and had necrotic immature permanent teeth. Quantitative assessments of crown shades of treated teeth were determined with VITA Easyshade® Advance 4.0 spectrophotometer (VITA Zahnfabrik, Bad Sackingen, Germany) at baseline to 24-month follow-up. Self-reported pain was measured using the visual analogue scale (VAS) at the time of treatment (shortly after induction of bleeding into the canal) and at 7 day following the procedure. At 12 months, radiographic lesions were resolved. At 24 months there were apical closures, and the three teeth remained in function without symptomatology or signs of failure. All cases had the root length increased and the dentin wall thickened. One case presented radiographic images suggestive of scattered calcified zones in the root canal lumen.

Conclusion

Emdogain may be beneficial as a scaffold in regenerative endodontic procedures. The following outcomes were noted at 24-month follow-up: continuity of root formation, thickening of the root dentin walls, and closure of the root apex.

Peer Review reports

Background

The prognosis for teeth that underwent pulp regenerative procedures depends on a variety of factors, including pre-, intra-, and postoperative variables. Although every factor may play an important role in the therapy outcome, in several cases, the clinical and radiographic results may be unpredictable.

Regenerative endodontic (or pulp revascularization) was suggested in 2004 as an alternative therapy to treat permanent immature (incomplete rhizogenesis) necrotic teeth [3]. Pulp regeneration consists of cleaning the root canal (no shaping or very gentle shaping) and inducing a blood clot that should originate from the periapical area and fill the canal space [3, 14]. The blood clot would serve then as a matrix to help the formation of new vital tissue—this occurs because it brings important cells coming from the apical region, responsible for tooth formation: the epithelial sheath of Hertwig (that normally would be available only until the complete root formation) [21]. The presence of cells from the apical papilla will contribute to finalizing the root development upon thickening the dentinal walls, increasing in root length, and ultimately, restoring the pulp vitality of those nonvital/necrotic teeth [2, 44].

Protocols for regenerative endodontic procedures vary in terms of the use of irrigating solutions [11, 34, 39], intracanal medication [3, 10, 17], scaffolds [24, 46], and materials for cervical sealing [10, 15, 31, 39]. Authors have stated that the predictability of outcomes in regenerative procedures depends on the eradication of infection [12], the source and duration of apical periodontitis (periapical lesion), or the severity of injury that the apical papilla and the stem cells (epithelial sheath of Hertwig) have undergone [8]. However, it is impossible to know the conditions of these factors in clinical practice; consequently, therapy outcomes are unpredictable.

A blood clot has been the main scaffold in the published case studies [6, 7, 9, 15, 18, 34, 39]. However, it would be advantageous if regenerative strategies using advanced scaffolds and growth factors could favor pulp and dentine regeneration. Several biomaterials have been investigated using animal models, such as alginate, hyaluronic acid, chitosan, PLLA NF-MS(Poly(L-lactic acid) Nanofiber Microspheres) with BMP-2 (Bone Morphogenetic Protein-2), PLGA-PEG (Poly(lacticco-glycolic acid)-Polyethylene Glycol) nanoparticles, and Vitrogel 3D with SDF-1a (Stromal Cell-Derived Factor 1 alpha) and BMP-2 [35].

It is well documented that the secretion of enamel matrix-derived proteins by Hertwig’s epithelial sheath triggers a cascade of reactions that stimulate odontogenesis [22, 42]. The enamel matrix derivative is commercially available as Emdogain (EMD, Straumann® Emdogain®, Basel, Switzerland) and is well recognized in periodontics for its regenerative potential [22]. In the conservative treatment of the pulp, EMD induces the formation of reparative dentin, protecting the pulp tissue from inflammation and degeneration [13, 29, 32]. In 2012, authors demonstrated that EMD, when used as an intracanal medication, was able to promote root development in rat teeth, similar to the triple antibiotic paste, which is the original intracanal medication indicated for regenerative therapy [38]. Another study evaluated the effects of EMD on the proliferation and differentiation of human dental pulp cells (hDPCs) in vitro. They concluded that EMD could enhance the mineralization of hDPCs and increased the expression of markers for odontoblast/osteoblast-like cells [45]. EMD has demonstrated recognized high biocompatibility and significant wound healing potential, as highlighted by Munar-Bestard et al. [25], who reported its favorable regenerative capacity and biocompatibility in comparison with other commercial periodontal gels. Nevertheless, EMD potential in regenerative endodontics is not yet fully understood, although it has shown an important role in odontogenesis, with potentiation of pulp tissue repair and regeneration [45].

The aim of this cases series was to present three clinical cases that had different preoperative conditions (such as, patient’s age, pulp/periapical diagnosis, and tooth type) and who underwent pulp regenerative procedures under an identical clinical protocol. In addition, this report also aimed to show the value of using EMD as a scaffold to guide angiogenesis and the healing process by reporting clinical and radiographical results.

Cases presentation

Study design and ethics

This report is a retrospective description of clinical findings from three regenerative treatments that were conducted under the same technique/protocol. The material used in the root canals as a scaffold was Emdogain (EMD, Straumann® Emdogain®, Basel, Switzerland), a gel formulation commercialized in a plastic syringe containing enamel matrix derivative. Patients’ parents signed an informed consent. Use of patient’s information to construct this article was approved by the Research Ethics Committee at the university/dental school where the treatments took place (approval no.: #2.997.609). This report was written according to Preferred Reporting Items for Case reports in Endodontics (PRICE) 2020 guidelines [27, 28].

Setting, patients, crown shades, and self-reported pain assessments

From October 2018 to February 2022, a total of three young patients (ages 8, 8, and 12 years old; all with brown skin color and Pardo ethnicity; one female and two male; and from low-income backgrounds with necrotic immature permanent teeth (mandibular molar, maxillary central incisor, and maxillary central incisor) underwent regenerative procedures performed in two appointments (with 2-week intervals in between sessions) at the dental school clinic. Medical history, dental history, and dental examination (including radiographs, periodontal evaluation, and pulp-periapical tests) were obtained before proceeding with the treatment. Patients were recalled at 3, 6, 12, 18, and 24 months for follow-up.

Quantitative assessments of crown shades of treated teeth were determined using the VITA Easyshade® Advance 4.0 spectrophotometer (VITA Zahnfabrik, Bad Sackingen, Germany) at baseline (before treatment), immediately after the completion of the treatment, and at each follow-up session.

Self-reported pain was measured using the visual analogue scale (VAS) with degrees numbered from 0 (no pain) to 10 (worst possible pain) at the time of treatment (shortly after induction of bleeding into the canal) and at 7 days following the procedure. The dental assistant helped the patient to point out a degree of pain in the VAS, since the patient was under rubber dam isolation.

Clinical procedure: regenerative treatment

The same regenerative treatment protocol was conducted by two operators/dentists in the three clinical cases.

In the first session, the dentist applied local anesthesia with 4% articaine 1:100,000 epinephrine (Nova DFL, Rio de Janeiro, Brazil), and rubber dam isolation with a single hole (in the tooth to be treated). Pulp chamber access opening was then performed to allow irrigation with 10 mL 2.5% sodium hypochlorite (NaOCl—Fórmula e Ação, São Paulo, Brazil) using 27-G irrigating tips (Ultradent Products Inc. South Jordan, Utah, USA). The working length was radiographically determined using stainless-steel K-files [the biggest size that could be gently fitted into the root canal(s)]. A gentle mechanical preparation (K-files) was performed in the coronal and middle third of the canals. Each canal was then irrigated with 10 mL 2.5% NaOCl and 10 mL ethylene diamine tetra acetic (EDTA) acid (Fórmula e Ação, São Paulo, Brazil). Final irrigation was performed with additional 10 mL 2.5% NaOCl, and 10 mL saline solution. Canals were dried with sterile paper points and medicated with calcium hydroxide (Ultracal—Ultradent, EUA). The access cavity was double sealed with sterile cotton pellet, temporary filling material (Coltosol®, Coltene, Rio de Janeiro, RJ, Brazil), and restorative glass ionomer cement Riva Light Cure (SDI, Victoria, Australia).

In the second session, the dentist applied a local anesthetic infusion without vasoconstrictor (2% lidocaine, Nova DFL, Rio de Janeiro, Brazil). Root canals were accessed and irrigated with 10 mL EDTA to remove calcium hydroxide, followed by a final rinse with 10 mL of saline solution. Canals were then dried with sterile paper points. Bleeding was generated by gently disrupting (upon shorter quarter-turn movements) periapical tissues 2 mm beyond the root apex with a size #40 K-file. Upon observing the initial outflow of blood in the root canal(s), the dentist inserted EMD (Emdogain® Institut Straumann AG, Basel, Switzerland), injecting it directly from the syringe and using the full amount of the medication (0.15 mL). In the subsequent minutes, a suitable blood clot (mixed with EMD) had formed. Therefore, approximately 2 mm thickness of white mineral trioxide aggregate (MTA; MTA Angelus, Londrina, Paraná, Brazil) was gently deposited and condensed in the coronal third of the canal. Restorative glass ionomer cement was placed over the MTA, followed by a composite resin restoration (3 M ESPE, St. Paul, MN). Periapical radiographs confirmed the MTA placement and final restoration.

Table 1 summarizes the technical information and treatment sequence.

Table 1 Technical information and treatment sequence for the three regenerative endodontic cases reported in this article
Full size table

Case 1

An 8-year-old female patient was referred to the comprehensive clinic at the dental school because of a facial swelling on the left side and fever. The person responsible for the child reported painful symptoms that had started 2 days prior. Medical history was noncontributory. Intraoral examination found edema around the apical region of tooth #3.6 (left mandibular first molar). Probing depths were within the normal limits. The tooth was nonresponsive to cold test and electrical pulp test (EPT), and positive for periapical palpation and vertical percussion (tenderness). The tooth crown was shade A2. The pulp chamber had been previously accessed and the tooth had a provisional restoration, however, carious tissue was still present (visualized clinically and radiographically). Periapical radiograph showed open apices in the mesial and distal roots and a periapical radiolucency at the distal root (Fig. 1A). Diagnosis for tooth #3.6 was pulp necrosis and acute apical abscess. The regenerative endodontic procedure was accepted by the patient’s guardian, and it was performed according to protocol (Table 1). The patient pointed at the worst pain possible (10 at VAS) during the induction of bleeding transoperatively. Bleeding time duration was 60 seconds. No pain occurred in the following week and at 7-day follow-up (0 at VAS). At 3-month follow-up the patient was asymptomatic (all clinical tests were within the normal limits). Radiograph showed that the periapical region had healed (Fig. 1B). At 6-month and 12-month follow-ups the patient remained asymptomatic (palpation and percussion negative), but with a positive/normal response for cold and EPT. Radiograph showed normal periodontal ligament and an increase in root length and width for tooth #3.6 (Fig. 1C and D). At 24-month follow-up the patient was still asymptomatic, and the tooth was responding to thermal and electrical tests. The color of the crown was shade A3. The apex of the mesial root was closed, and the periodontal ligament was within the normal limits (Fig. 1E).

Fig. 1
figure 1

Case 1: tooth #3.6. A Preoperative periapical radiograph (PA). B PA at 3 months following the regenerative endodontic procedure with Emdogain as scaffold. C PA at 6-month follow-up showing the continuity of root length formation. D PA at 12-month follow-up, showing the complete absence of a periapical lesion. E PA at 24-month follow-up, with closure of root apex

Full size image

Case 2

An 8-year-old male patient was referred to the comprehensive clinic at the dental school because of a tooth fracture. The person responsible for the child reported that a trauma in the mouth had occurred at the school 15 days prior. Medical history was noncontributory. Intraoral examination found an uncomplicated crown fracture (involving enamel and dentin) in tooth #1.1 (right maxillary central incisor). Probing depths were within the normal limits. The tooth was nonresponsive to cold test and electrical pulp test (EPT), and negative for periapical palpation and vertical percussion. The tooth crown was shade B2. Periapical radiograph showed open apex and no periapical radiolucency (Fig. 2A). Diagnosis for tooth #1.1 was pulp necrosis with normal apical tissues. The regenerative endodontic procedure was accepted by the patient’s guardian, and it was performed according to protocol (Table 1). The patient pointed at severe pain (8 at VAS) during the induction of bleeding transoperatively. Bleeding time duration was 50 seconds. At 7-day follow-up no pain was reported for the day and the week before (0 at VAS). The tooth was then restored with composite resin. At 3-month follow-up the patient was asymptomatic and the tooth unresponsive to thermal and electrical tests. The color of the crown became darker (shade C3). Radiographic examination showed continuity of root length formation and a radiopaque image in coronal third of the canal, suggestive of hard tissue formation (Fig. 2B). At 6-month follow-up the patient remained asymptomatic, and the tooth was unresponsive for pulp tests. The color of the crown became darker (shade C4). Root length formation and the radiopaque image in coronal third of the canal were more evident (Fig. 2C). At 12-month follow-up the tooth was now responding positive/normal to pulp tests, but the color of crown remained shade C4 (Fig. 2D). At 24-month follow-up the clinical signs remained unchanged. The root apex had closed, and the periodontal ligament was normal (Fig. 2E).

Fig. 2
figure 2

Case 2: tooth #1.1. A Preoperative periapical radiograph (PA). B PA at 3 months following the regenerative endodontic procedure with Emdogain as scaffold. C PA at 6-month follow-up showing continuity of root length formation and appearance of radiopaque images (suggestive images of calcified material) within the root canal. D and E PA taken at 12 and 24 months, respectively, showing radiopaque images, dentinal thickening, and apical closure

Full size image

Case 3

A 12-year-old male patient was referred to the comprehensive clinic at the dental school for restorative treatment. The person responsible for the child reported that a trauma in the mouth had occurred more than a year ago. Medical history was noncontributory. Intraoral examination found a provisional restoration on tooth #2.1 (left maxillary central incisor) and crown discoloration (shade A3). Probing depths were within the normal limits. The tooth crown was shade A3. The tooth was nonresponsive to cold test and electrical pulp test (EPT), and negative for periapical palpation and vertical percussion. Periapical radiograph showed pen apex and a periapical radiolucency (Fig. 3A). Diagnosis for tooth #2.1 was pulp necrosis and asymptomatic apical periodontitis. The regenerative endodontic procedure was accepted by the patient’s guardian, and it was performed according to protocol (Table 1). The patient pointed at severe pain (8 at VAS) during the induction of bleeding transoperatively. Bleeding time duration was 27 seconds. At 7-day follow-up no pain was reported for the day and the week before (0 at VAS). At 3-month follow-up the patient was asymptomatic and the tooth was unresponsive to thermal and electrical tests. The color of the crown had changed to shade C3. At 6-month follow-up the patient remained asymptomatic, and the tooth was unresponsive to pulp tests. The tooth color continued to be C3. Radiographic examination showed continuity of root length formation and a potential closure of the apex (Fig. 3C). At 18-month follow-up tooth remained unresponsive to pulp tests, but the color was at this time shade B3. There was continuity of root formation, slight apical closure, periodontal ligament normal, and periapical healing (Fig. 3D).

Fig. 3
figure 3

Case 3: tooth #2.1. A Preoperative periapical radiograph (PA). B PA at 3 months following the regenerative endodontic procedure with Emdogain as scaffold. C PA at 6-month follow-up showing mild root thickening. D and E PA at 12- and 24-month follow-ups, respectively, showing mild root thickening, tendency to close the root apex, and regression of the periapical lesion

Full size image

Table 2 presents some of the pre-, trans-, and postoperative factors for each one of the reported cases.

Table 2 Pre-, trans-, and postoperative factors for each one of the reported cases of regenerative therapy. All cases were followed up to 24 months
Full size table

Discussion and conclusion

Several factors that can affect clinical outcomes of regenerative procedures were pointed out in the document from the American Association of Endodontists (AAE) titled “Clinical Considerations for a Regenerative Procedure” (AAE 2018), and the goals were classified as: primary (the resolution of signs and symptoms of infection), secondary (further root maturation is desirable), and tertiary (return of neurogenesis). After regenerative endodontic procedures in nonvital immature teeth, a 20% increase in root canal wall is usually required to produce a significant clinical effect (strengthening of tooth structure). For this, little or no instrumentation is indicated [37].

In the present case series, all cases had dentinal thickening and a tendency to close the apex. In addition, radiopaque deposits were observed in the root canal. Two cases had positive responses to pulp sensitivity tests at different moments (case 1 from 6-month to 24-month follow-up and case 2 at 12-month follow-up). Patients from the reported case 2 and case 3 had a history of dental trauma. All teeth showed resolution of signs and symptom.

The literature has showed some cases with suboptimal clinical results, such as absence of increase in root length [31, 34], absence of increase in root wall thickness [7, 34], or lack of formation of tooth apex, and formation of a hard-tissue barrier inside the canal between the coronal MTA plug and the root apex [7]. In this study, none of the three reported cases had a complete obliteration with hard tissue in the root canal at 24-month follow-up. However, it is important to bear in mind that this unwanted outcome can have long-term results.

It has also been speculated that there would be a relationship between the duration of pulp necrosis and the outcome of the treatment [31]. In this line, we showed in this report that case 2 had radiopaque images inside the root canal, suggestive of calcified tissue, which therefore could be a correlation between dental history and quality of root development because of the longer duration of pulp necrosis.

Lack of continued root development following regenerative endodontic procedures is likely due to severe damage to the stem cells, because they regulate the root development. If the apical papilla is severely damaged, there will be no newly differentiated odontoblasts to produce root dentine. However, the survival of the apical papilla, Hertwig’s epitelial root sheath, and dental follicle in immature permanent teeth with pulpal infection or dental trauma is not under the full control of the clinician. It is interesting that some previous studies have shown sufficient root development, but at the same time, the tooth was unresponsive to pulp tests. This may happen because, as such histological examinations have proven, regeneration may have happened upon the formation of periodontal- and bone-like tissues rather than a pulp–dentine complex [4, 19, 23, 30, 40, 41, 43].

Intra- and postoperative pain were assessed in this case series (through VAS scales). Pain is a relevant factor for patients and can impact the dental procedure, as well as patients’ quality of life. Pain during the dental procedure, especially in children and adolescents, is challenging for the dentist, sometimes impairing the continuation of the treatment. Patients’ quality of life can reduce as a consequent of pain, impairing speech, chewing, and social and psychological aspects (for instance, difficulty relaxing and irritability) [20, 33]. This report showed that the three patients had pain during the procedure (at the time of bleeding induction) ranging from 1 (mild pain) to 10 (worst possible pain). Using local anesthetics without vasoconstrictors is recommended to facilitate bleeding after root canal disinfection [34]; however, alternatives to pain mitigation should be sought at this stage, as patient collaboration is essential for a technically appropriate clinical procedure. Conversely, postoperatively there was no manifestation of pain in our three patients. Awareness of the negative impacts felt by the patient—either in intra- or postoperative phases—is important for taking precautions in future treatments for the same patient.

The three patients presented tooth discoloration after 24 months following the regenerative procedure. Studies reported a percentage ranging from 44% to 83% of coronal discoloration [26, 36]. The mechanism of discoloration is most evident when tetracycline-based antibiotics (minocycline or doxycycline) were used as intracanal medication. In the present report, even with the choice of using calcium hydroxide as medication, we noticed considerable crown discoloration. In addition, mineral trioxide aggregate (MTA), which was used over the blood clot at the coronal third of the root canals, may also have played a role in making the teeth darker [1, 7, 16]. Authors have shown that using MTA as a pulp capping material had caused considerable discoloration [5]. In vital pulp therapy (pulp capping and pulpotomy), it is assumed that the chances of discoloration are greater because the material is placed at the crown level and not at the root level (as in regenerative procedures).

One challenge concerning the cases reported here was that of maintaining the bioceramic material (MTA) in the coronal third of larger root canals without it leaking to the rest of the canal. Our case 3 exemplifies this difficulty, since the radiographs show some material beyond the coronal third. This case series is strong because it is the first to be published using EMD as scaffold for regenerative procedures. Although case reports do not provide definitive evidence to support the treatment protocol, they have the advantage of being performed in real patients and may provide future guidelines for other study designs.

This report showed that EMD may be beneficial as a scaffold in regenerative endodontic procedures. The following outcomes were noted at 24-month follow-up: continuity of root formation, thickening of the root dentin walls, and closure of the root apex.

Availability of data and materials

The datasets used and analyzed during the current study available from the corresponding author on reasonable request.

Abbreviations

EMD:

Emdogain

VAS:

Visual analogue scale

PRICE:

Preferred reporting items for case reports in endodontics

EDTA:

Ethylene diamine tetra acetic acid

MTA:

Mineral trioxide aggregate

AAE:

American Association of Endodontists

References

  1. Ahmed HM, Abbott PV. Discolouration potential of endodontic procedures and materials: a review. Int Endod J. 2012;45(10):883–97.

    Article  CAS  PubMed  Google Scholar

  2. Al Ansary MA, Day PF, Duggal MS, Brunton PA. Interventions for treating traumatized necrotic immature permanent anterior teeth: inducing a calcific barrier & root strengthening. Dent Traumatol. 2009;25(4):367–79.

    Article  PubMed  Google Scholar

  3. Banchs F, Trope M. Revascularization of immature permanent teeth with apical periodontitis: new treatment protocol? J Endod. 2004;30(4):196–200.

    Article  PubMed  Google Scholar

  4. Becerra P, Ricucci D, Loghin S, Gibbs JL, Lin LM. Histologic study of a human immature permanent premolar with chronic apical abscess after revascularization/revitalization. J Endod. 2014;40(1):133–9.

    Article  PubMed  Google Scholar

  5. Belobrov I, Parashos P. Treatment of tooth discoloration after the use of white mineral trioxide aggregate. J Endod. 2011;37(7):1017–20.

    Article  PubMed  Google Scholar

  6. Cehreli ZC, Isbitiren B, Sara S, Erbas G. Regenerative endodontic treatment (revascularization) of immature necrotic molars medicated with calcium hydroxide: a case series. J Endod. 2011;37(9):1327–30.

    Article  PubMed  Google Scholar

  7. Chen MY, Chen KL, Chen CA, Tayebaty F, Rosenberg PA, Lin LM. Responses of immature permanent teeth with infected necrotic pulp tissue and apical periodontitis/abscess to revascularization procedures. Int Endod J. 2012;45(3):294–305.

    Article  PubMed  Google Scholar

  8. Chrepa V, Joon R, Austah O, Diogenes A, Hargreaves KM, Ezeldeen M, Ruparel NB. Clinical outcomes of immature teeth treated with regenerative endodontic procedures-a san antonio study. J Endod. 2020;46(8):1074–84.

    Article  PubMed  Google Scholar

  9. Chueh LH, Ho YC, Kuo TC, Lai WH, Chen YH, Chiang CP. Regenerative endodontic treatment for necrotic immature permanent teeth. J Endod. 2009;35(2):160–4.

    Article  PubMed  Google Scholar

  10. Chueh LH, Huang GT. Immature teeth with periradicular periodontitis or abscess undergoing apexogenesis: a paradigm shift. J Endod. 2006;32(12):1205–13.

    Article  PubMed  Google Scholar

  11. Ding RY, Cheung GS, Chen J, Yin XZ, Wang QQ, Zhang CF. Pulp revascularization of immature teeth with apical periodontitis: a clinical study. J Endod. 2009;35(5):745–9.

    Article  PubMed  Google Scholar

  12. Diogenes AR, et al. An update on clinical regenerative endodontics. Endod Top. 2013;28:2–23.

    Article  Google Scholar

  13. Igarashi R, Sahara T, Shimizu-Ishiura M, Sasaki T. Porcine enamel matrix derivative enhances the formation of reparative dentine and dentine bridges during wound healing of amputated rat molars. J Electron Microsc. 2003;52(2):227–36.

    Article  CAS  Google Scholar

  14. Iwaya SI, Ikawa M, Kubota M. Revascularization of an immature permanent tooth with apical periodontitis and sinus tract. Dent Traumatol. 2001;17(4):185–7.

    Article  CAS  PubMed  Google Scholar

  15. Jadhav G, Shah N, Logani A. Revascularization with and without platelet-rich plasma in nonvital, immature, anterior teeth: a pilot clinical study. J Endod. 2012;38(12):1581–7.

    Article  PubMed  Google Scholar

  16. Kahler B, Rossi-Fedele G. A review of tooth discoloration after regenerative endodontic therapy. J Endod. 2016;42(4):563–9.

    Article  PubMed  Google Scholar

  17. Kim DS, Park HJ, Yeom JH, Seo JS, Ryu GJ, Park KH, Shin SI, Kim SY. Long-term follow-ups of revascularized immature necrotic teeth: three case reports. Int J Oral Sci. 2012;4(2):109–13.

    Article  PubMed  PubMed Central  Google Scholar

  18. Kontakiotis EG, Filippatos CG, Agrafioti A. Levels of evidence for the outcome of regenerative endodontic therapy. J Endod. 2014;40(8):1045–53.

    Article  PubMed  Google Scholar

  19. Lei L, Chen Y, Zhou R, Huang X, Cai Z. Histologic and immunohistochemical findings of a human immature permanent tooth with apical periodontitis after regenerative endodontic treatment. J Endod. 2015;41(7):1172–9.

    Article  PubMed  Google Scholar

  20. Liu P, McGrath C, Cheung G. What are the key endodontic factors associated with oral health-related quality of life? Int Endod J. 2014;47(3):238–45.

    Article  CAS  PubMed  Google Scholar

  21. Lovelace TW, Henry MA, Hargreaves KM, Diogenes A. Evaluation of the delivery of mesenchymal stem cells into the root canal space of necrotic immature teeth after clinical regenerative endodontic procedure. J Endod. 2011;37(2):133–8.

    Article  PubMed  Google Scholar

  22. Lyngstadaas SP, Wohlfahrt JC, Brookes SJ, Paine ML, Snead ML, Reseland JE. Enamel matrix proteins; old molecules for new applications. Orthod Craniofac Res. 2009;12(3):243–53.

    Article  CAS  PubMed  PubMed Central  Google Scholar

  23. Martin G, Ricucci D, Gibbs JL, Lin LM. Histological findings of revascularized/revitalized immature permanent molar with apical periodontitis using platelet-rich plasma. J Endod. 2013;39(1):138–44.

    Article  PubMed  Google Scholar

  24. Miltiadous ME, Floratos SG. Regenerative endodontic treatment as a retreatment option for a tooth with open apex—A case report. Braz Dent J. 2015;26(5):552–6.

    Article  PubMed  Google Scholar

  25. Munar-Bestard M, Llopis-Grimalt MA, Ramis JM, Monjo M. Comparative in vitro evaluation of commercial periodontal gels on antibacterial, biocompatibility and wound healing ability. Pharmaceutics. 2021;13(9):1502.

    Article  CAS  PubMed  PubMed Central  Google Scholar

  26. Nagata JY, Gomes BP, Rocha Lima TF, Murakami LS, de Faria DE, Campos GR, de Souza-Filho FJ, Soares AJ. Traumatized immature teeth treated with 2 protocols of pulp revascularization. J Endod. 2014;40(5):606–12.

    Article  PubMed  Google Scholar

  27. Nagendrababu V, et al. PRICE 2020 guidelines for reporting case reports in endodontics: explanation and elaboration. Int Endod J. 2020;53:922–47.

    Article  CAS  PubMed  Google Scholar

  28. Nagendrababu V, et al. PRICE 2020 guidelines for reporting case reports in endodontics: a consensus-based development. Int Endod J. 2020;53:619–26.

    Article  CAS  PubMed  Google Scholar

  29. Nakamura Y, Hammarström L, Matsumoto K, Lyngstadaas SP. The induction of reparative dentine by enamel proteins. Int Endod J. 2002;35(5):407–17.

    Article  CAS  PubMed  Google Scholar

  30. Nosrat A, Kolahdouzan A, Hosseini F, Mehrizi EA, Verma P, Torabinejad M. Histologic outcomes of uninfected human immature teeth treated with regenerative endodontics: 2 case reports. J Endod. 2015;41(10):1725–9.

    Article  PubMed  Google Scholar

  31. Nosrat A, Seifi A, Asgary S. Regenerative endodontic treatment (revascularization) for necrotic immature permanent molars: a review and report of two cases with a new biomaterial. J Endod. 2011;37(4):562–7.

    Article  PubMed  Google Scholar

  32. Olsson H, Davies JR, Holst KE, Schröder U, Petersson K. Dental pulp capping: effect of emdogain gel on experimentally exposed human pulps. Int Endod J. 2005;38(3):186–94.

    Article  CAS  PubMed  Google Scholar

  33. Pasqualini D, Corbella S, Alovisi M, Taschieri S, Del Fabbro M, Migliaretti G, Carpegna GC, Scotti N, Berutti E. Postoperative quality of life following single-visit root canal treatment performed by rotary or reciprocating instrumentation: a randomized clinical trial. Int Endod J. 2016;49(11):1030–9.

    Article  CAS  PubMed  Google Scholar

  34. Petrino JA, Boda KK, Shambarger S, Bowles WR, McClanahan SB. Challenges in regenerative endodontics: a case series. J Endod. 2010;36(3):536–41.

    Article  PubMed  Google Scholar

  35. Raddall G, Mello I, Leung BM. Biomaterials and scaffold design strategies for regenerative endodontic therapy. Front Bioeng Biotechnol. 2019;15(7):317.

    Article  Google Scholar

  36. Saini HR, Tewari S, Sangwan P, Duhan J, Gupta A. Effect of different apical preparation sizes on outcome of primary endodontic treatment: a randomized controlled trial. J Endod. 2012;38(10):1309–15.

    Article  PubMed  Google Scholar

  37. Saoud TM, Mistry S, Kahler B, Sigurdsson A, Lin LM. Regenerative endodontic procedures for traumatized teeth after horizontal root fracture, avulsion, and perforating root resorption. J Endod. 2016;42(10):1476–82.

    Article  PubMed  Google Scholar

  38. Scarparo RK, Dondoni L, Böttcher DE, Grecca FS, Figueiredo JA, Batista EL Jr. Apical periodontium response to enamel matrix derivative as an intracanal medication in rat immature teeth with pulp necrosis: radiographic and histologic findings. J Endod. 2012;38(4):449–53.

    Article  PubMed  Google Scholar

  39. Shah N, Logani A, Bhaskar U, Aggarwal V. Efficacy of revascularization to induce apexification/apexogensis in infected, nonvital, immature teeth: a pilot clinical study. J Endod. 2008;34(8):919–25.

    Article  PubMed  Google Scholar

  40. Shimizu E, Jong G, Partridge N, Rosenberg PA, Lin LM. Histologic observation of a human immature permanent tooth with irreversible pulpitis after revascularization/regeneration procedure. J Endod. 2012;38(9):1293–7.

    Article  PubMed  Google Scholar

  41. Shimizu E, Ricucci D, Albert J, Alobaid AS, Gibbs JL, Huang GT, Lin LM. Clinical, radiographic, and histological observation of a human immature permanent tooth with chronic apical abscess after revitalization treatment. J Endod. 2013;39(8):1078–83.

    Article  PubMed  Google Scholar

  42. Sonoyama W, Seo BM, Yamaza T, Shi S. Human Hertwig’s epithelial root sheath cells play crucial roles in cementum formation. J Dent Res. 2007;86(7):594–9.

    Article  CAS  PubMed  Google Scholar

  43. Torabinejad M, Faras H. A clinical and histological report of a tooth with an open apex treated with regenerative endodontics using platelet-rich plasma. J Endod. 2012;38(6):864–8.

    Article  PubMed  Google Scholar

  44. Wang X, Thibodeau B, Trope M, Lin LM, Huang GT. Histologic characterization of regenerated tissues in canal space after the revitalization/revascularization procedure of immature dog teeth with apical periodontitis. J Endod. 2010;36(1):56–63.

    Article  PubMed  Google Scholar

  45. Wang Y, Zhao Y, Ge L. Effects of the enamel matrix derivative on the proliferation and odontogenic differentiation of human dental pulp cells. J Dent. 2014;42(1):53–9.

    Article  PubMed  Google Scholar

  46. Zhujiang A, Kim SG. Regenerative endodontic treatment of an immature necrotic molar with arrested root development by using recombinant human platelet-derived growth factor: a case report. J Endod. 2016;42(1):72–5.

    Article  PubMed  Google Scholar
